Remora3 Global
Remora3 Global is a rugged global GPS tracker with Bluetooth and 10+ year battery life. Track assets worldwide with ease. Contact us today to get started.
Höjdpunkter
Global Connectivity
The Remora3 Global connects to all major 4G Cat 1bis and 2G bands to enable global asset visibility.
Bluetooth® Gateway
Bluetooth® 5.2 Gateway for affordable tagged asset management and sensor monitoring applications.
Off-the-Shelf Batteries
Powered by 2 x D Cell Lithium Thionyl Chloride (LTC) batteries with built-in ‘Battery Low’ and ‘Battery Critical’ alerts.
Theft Recovery
Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval.
Flash Memory
Store weeks of records if device is out of cellular coverage. Storage capacity for over 28 days of continuous 30-second logging.
Rugged & Weatherproof
Ultra-rugged and waterproof housing ensures the Remora3 Global can withstand impact, fine dust, and brief submersion.
Wire-Free Installation
Compact and concealable. Multiple installation options for covertly and easily securing the device to assets with screws, bolts, cable ties, rivets, and more. Stainless steel screws supplied.
Flexible Configuration
Configure device parameters such as heartbeat rate, movement and accelerometer settings, and more to fit any tracking application.
Tekniska specifikationer
Connectivity
- Cellular Module
- u-blox LENA R8 operates on all major global 4G LTE Cat 1bis and 2G bands. Supported 4G LTE Cat 1bis bands:B1, B2, B3, B4, B5, B7, B12, B20, B28, B38, B40, B41, B66 Quad-band 2G support for global 2G networks.
- Bluetooth®
- Bluetooth 5.2 gateway reports nearby Bluetooth tags and sensors for affordable tagged asset management and sensor monitoring.
- SIM Size and Access
- Internal Nano 4FF SIM
Location
- GNSS Module
- u-blox M10
- Environment
- Outdoor
- Constellations
- Concurrent GPS, GLONASS, BeiDou, Galileo
- GNSS Assistance
- GNSS almanac and ephemeris data for greater sensitivity and position accuracy.
- Low Noise Amplifier
- GPS signals are filtered and boosted by a SAW filter and low-noise amplifier (LNA) allowing operation where other units fail.
- Cell Tower Location
- Sends cell tower data when GNSS signal is unavailable.
- Location Accuracy*
- ~2m CEP * Positioning accuracy specifications are provided by the module supplier and reflect ideal conditions. Device configuration, installation, environmental conditions, augmentation services, and many other factors may lead to variations in positioning accuracy.
Power
- User-Replaceable Batteries
- 2 x D (3.6V per cell). Batteries not included.
- Supported Battery Types
- Lithium Thionyl Chloride (LTC)Battery selection is very important. Follow this link to learn more. Please dispose of Lithium batteries in a safe and responsible manner.
- Battery Life Estimates*
- Once Daily location updates – 10 yearsMovement-Based location updates** – 9 yearsHourly location updates – 7 years
- Sleep Current
- <10uAAverage current in lowest power state. * Battery life estimates are influenced by several factors including temperature, installation and orientation of the device, battery selection, the frequency of location updates, network coverage, sensor integrations, peripherals, accelerometer settings, and more. Battery life calculators are available at support.digitalmatter.com. ** Movement-based estimates are based on 2 hours of movement, occurring 5 days a week, with default trip tracking parameters (location updates every 3 minutes and uploads every 30 minutes). Devices can be configured to provide more frequent location updates when the asset is in motion which will impact battery life.
Mechanics / Design
- Dimensions
- 222 x 91 x 41 mm (8.74 x 3.58 x 1.61 in)
- Device Weight
- 457g with Lithium Thionyl Chloride batteries.
- Housing
- Non-branded nylon glass housing is suitable for white labeling.
- IP/IK Rating
- Ultra-rugged and waterproof IP68 and IK07-rated housing ensures the device can withstand impact, fine dust, and brief submersion.
- Installation
- Compact and concealable. Multiple installation options for covertly and easily securing the device to assets with screws, bolts, cable ties, rivets, and more. Stainless steel screws provided.
- External Magnet
- Removal of magnet enables tamper detection.
- Temperature Range
- Operating: -30°C to +60°CRecommended Storage: 10°C to 30°C, Humidity 30%. Store in a cool, dry place.
- Cellular Antenna
- Internal
- GPS Antenna
- Internal
- 3-Axis Accelerometer
- 3-Axis accelerometer to detect movement, high-g events, and more.
- Diagnostic LED
- Diagnostic LED indicates operation status.
- Flash Memory
- Store records if device is out of cellular coverage. View storage capacity here.
- Onboard Speed and Heading
- Current speed and heading is reported with each position update.
- Onboard Temperature
- Provides ambient temperature but may not be suitable for precise temperature logging purposes.
Smarts
- Adaptive Tracking
- Configure parameters to send updates based on set time intervals or when movement occurs. Adaptive tracking technology detects when the device is on the move and increases the update rate, providing detail when you need it while conserving battery when stationary.
- Battery Life Monitoring
- ‘Battery Low’ and ‘Battery Critical’ alert levels.
- Geofencing
- The server can use device location to create geofences and alerts if an asset enters or leaves designated locations. Geofences can also be downloaded directly to the device for enhanced location-based actions and alerts. View storage capacity here.
- Impact Detection
- Configure impact-detection alerts when g-forces are exceeded by a user-defined threshold.
- Rotation Counting
- Keeps a count of the number of rotations of the device.
- Run Hour Monitoring
- Capture run hours based on movement to understand and optimize asset utilization.
- Sleep Mode
- Stationary devices enter sleep mode until movement occurs to conserve battery life and optimize data usage.
- Tamper Detection
- External magnet provides an alert if the device is removed from your asset.
- Theft Recovery
- Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval.
- Tip Detection
- Define a range of angles that constitutes a ‘tipped’ state and configure alerts.
Device Management
- Flexible Configuration
- Configure device parameters such as position update rate, movement and accelerometer settings, and more to fit any tracking application.
- Device Management Platform
- Manage, monitor, configure, debug, update, and restart devices remotely from our cloud-based device management system.
- Configuration App
- Configurable with DM-Link provisioning tool.
Integration
- Third-Party Integration
- TCP Direct or HTTPS Webhook
- API
- Command and configure the device via rich API functionality.
Security
- Data Security
- Military-grade AES-256 Encryption from device to Device Manager to protect the integrity and confidentiality of your data. Data forwarded to third-party systems is sent via HTTPS for end-to-end security.
Warranty
- Manufacturer’s Warranty
- Two-year manufacturer’s warranty. Exclusions apply.
Produktvarianter
Remora3
LTE-M (Cat-M1) / NB-IoT / Bluetooth®
Rugged GPS tracker and Bluetooth® Gateway with the longest battery life on the market for asset tracking and wireless condition monitoring.
Remora3 Global
2G / 4G LTE Cat 1bis / Bluetooth®
Rugged GPS tracker and Bluetooth® Gateway with 4G/2G connectivity for global asset tracking and wireless condition monitoring.
Vanliga frågor om Remora3 Global
Vad är Remora3 Global?
Remora3 Global kombinerar Remora3:s legendariska 10-åriga batteritid med global LTE-M och NB-IoT uppkoppling. Samma robusta hårdvara fungerar på alla stora marknader utan hårdvaruvarianter. Viktiga egenskaper inkluderar: Global Connectivity. Bluetooth® Gateway. Off-the-Shelf Batteries.
Vilken uppkoppling använder Remora3 Global?
Se fliken Tekniska data för exakta uppkopplings- och nätverksalternativ. GPS Logik kan alltid hjälpa till att välja rätt variant för svenska nätverk.
Hur lång är batteritiden för Remora3 Global?
Batteritiden beror på rapporteringsfrekvens, antal GPS-fixar per dag och vilken sensor som är ansluten. Fullständig batteriindikation finns i Digital Matters datasheet – ladda ner den överst på sidan. Kontakta våra telematikexperter om du vill ha en exakt livscykelberäkning för ditt driftfall.
Har Remora3 Global IP-klassning för damm och väta?
Samtliga Digital Matter-enheter har IP67- eller IP68-klassade höljen och klarar tuffa utomhus- och industrimiljöer. Exakt klassning per variant hittar du i fliken Tekniska data samt i datasheet.
Fungerar Remora3 Global med Telematics Guru och andra molnplattformar?
Remora3 Global skickar data till Digital Matters Telematics Guru som standard. Enheten kan också integreras mot egna molnplattformar, Wialon, Ubidots, AWS IoT och andra system via DMs API och MQTT. GPS Logik hjälper dig komma igång med den molnplattform du föredrar.
Vad ingår vid köp av Remora3 Global från GPS Logik?
Du får en ny Digital Matter-enhet direkt från tillverkaren, svensk faktura, snabb leverans från Stockholm, svensk support och hjälp att komma igång med Telematics Guru eller annan molnplattform. Kontakta oss för offert och volymrabatter.
Får jag svensk support och garanti?
Ja. Som auktoriserad nordisk återförsäljare av Digital Matter hanterar GPS Logik både försäljning, svensk förstalinjesupport och garantiärenden. Du behöver aldrig kontakta Australien för att få hjälp.
Relaterade Digital Matter-produkter
Remora3 Global kombinerar Remora3:s legendariska 10-åriga batteritid med global LTE-M och NB-IoT uppkoppling. Samma robusta hårdvara fungerar på alla stora marknader utan hårdvaruvarianter.
Varför välja Remora3 Global?
Byggd för export-tillgångar, internationella container-flottor och projektlogistik över landsgränser. Som auktoriserad nordisk partner till Digital Matter levererar GPS Logik Remora3 Global med svensk support, certifiering mot svenska mobilnät och snabb leverans från Stockholm.
Köp Remora3 Global hos GPS Logik
Behöver du hjälp att välja rätt hårdvara och molnplattform för din applikation? Kontakta oss så hjälper våra telematik-experter dig att komma igång med Remora3 Global. Fullständiga tekniska specifikationer och alla produktvarianter hittar du i flikarna ovan.
